該機組是采用電加熱提供熱源的一種瞬時滅菌設備、熱效率高、操作簡單。
●采用進口電腦程序控制系統和電器配件，觸摸屏人機界面。
●具有連續均質預熱功能、超高溫滅菌功能、管道消毒功能。
●冰水制冷(冰水)冷卻功能、CIP自動清洗功能
●在線顯示4位溫度曲線，控溫準確，加熱控溫精度±1℃
可用于鮮牛奶、乳飲料、豆奶、果蔬飲料、酒類等生產工藝中95-137℃巴氏殺菌、超巴氏殺菌、UHT超高溫殺菌。屬于一機多用設備，適用于大中院校、科研所(企業)的產品小試或中試用。
The unit is the use of electric heating to provide a heat source of a transient sterilization equipment, high thermal efficiency, simple operation.
● Imported computer program control system and electrical accessories, touch screen man-machine interface.
● With continuous homogenization function, ultra-high temperature sterilization function, pipeline disinfection function.
● Ice water cooling (ice water) cooling function, CIP automatic cleaning function
● online display 4-bit temperature curve, temperature control accuracy, heating temperature control accuracy ± 1 ℃
Can be used for fresh milk, milk drinks, soy milk, fruit and vegetable drinks, alcohol and other production processes in the 95-137 ℃ pasteurization, ultra-pasteurization, UHT ultra-high temperature sterilization. Belong to a multi-purpose equipment, suitable for large and medium-sized institutions, research institutes (enterprises) of small products or trial.
|
