該機組是由蒸汽提供熱源的一種滅菌設備，廣泛適用于保質期長的純牛奶、鮮牛奶、豆奶花色奶、乳飲料超巴氏殺菌、UHT超高溫殺菌。
●替代進口設備：具有自動完成消毒程序、生產程序、CIP清洗程序的全過程控制運行及監控，基本實現無人值守
●全部采用進口PLC程序控制器、觸摸屏人機界面、施耐德電氣 原件、斯派莎克蒸汽閥組、衛生級氣動(電磁)閥組
●具有均質功能
●預殺菌功能
●CIP清洗功能
●管道消毒功能
●具有冰水(冷水)冷卻功能
●機組與灌裝機直連和控制系統相互通訊功能
●滿足多產品、多工藝參數、多生產能力的轉換和不同的滅菌溫度要求
The unit is provided by the steam source of a sterilization equipment, widely used in long shelf life of pure milk, fresh milk, soy milk color milk, milk drinks ultra-pasteurization, UHT ultra-high temperature sterilization.
●Replacement of imported equipment: with automatic completion of the disinfection procedures, production procedures, CIP cleaning procedures for the whole process control operation and monitoring, the basic realization of unattended
●all imported PLC program controller, touch screen man-machine interface, Schneider Electric original, Shake steam valve group, sanitary pneumatic (solenoid) valve group
●with homogeneous function
● pre-sterilization function
●CIP cleaning function
●pipeline disinfection
●with ice water (cold water) cooling function
●unit and filling machine direct and control。System communication function
●to meet the multi-product, multi-process parameters, multi-productive capacity conversion and different sterilization temperature requirements
|
